Next-Generation Power, Uncompromising Safety
Launching in 2026, Genezen’s Semi-Solid LFP system delivers unprecedented amounts of clean energy.
High-capacity energy storage engineered for the next generation of large-scale power.
Genezen is introducing a next-generation energy storage solution in early 2026. A Semi-Solid LFP battery system that delivers unprecedented safety and power density.
With its advanced thermal stability and robust design, it offers peace of mind for high-capacity applications without compromising performance.
The New Genezen LFP is engineered to meet the toughest demands of critical industries. From powering freight trucks to more efficient power storage.
The Genezen Semi-Solid LFP Cell combines fast performance with lasting reliability. Built for 1.5C charging and discharging, its low internal resistance supports stable high-rate operation. Carbon enhancements across the cathode create uniform particle distribution, extending cycle life and ensuring consistent power delivery.
| Item | Description | Genezen 102Ah | Genezen LFP 280Ah | Genezen LFP 304AH | Genezen LFP 314Ah |
|---|---|---|---|---|---|
|
Size (H*W*D) |
Containing pole & outer film |
118.60×160.3×49.90 |
207.01*173.80*71.72 |
207.01*173.80*71.72 |
207.01*173.80*71.72 |
|
Capacity |
25°C@0.5C/0.5C |
≥102Ah |
≥280Ah |
≥304Ah |
≥314Ah |
|
Gravimetric Energy Density |
25°C 0.5C/0.5C |
≥160Wh/kg |
≥165Wh/kg |
≥175Wh/kg |
≥185Wh/kg |
|
Volumetric Energy Density |
25°C 0.5C/0.5C |
345Wh/L |
354Wh/L |
380Wh/L |
394Wh/L |
|
ACR |
25°C, 1kHz |
0.25-0.35 |
0.15-0.25mΩ |
0.15-0.25mΩ |
0.15-0.25mΩ |
|
DCR |
25°C @50% SOC(2C30s) |
≤1.5mΩ |
≤0.5mΩ |
≤0.5mΩ |
≤0.5mΩ |
|
Max. Continuous Charging Current |
– |
1C |
1C |
1.5C(15%-95%) |
1C |
|
Discharge Temperature |
– |
-30°C-60°C |
-30°C-60°C |
-30°C-60°C |
-30°C-60°C |
|
Battery Efficiency |
0.5P/0.5P |
≥95% |
≥95% |
≥95% |
≥95% |
|
Cycle Life |
0.5P/0.5P@80%SOH |
/ |
6000 cycles |
/ |
6000 cycles |
|
“ |
0.5P/0.5P@70%SOH |
6000 cycles |
8000 cycles |
/ |
8000 cycles |
|
“ |
1P/1P@70%SOH |
/ |
/ |
6000 cycles |
6000 cycles |
|
“ |
Step Charge 1C/0.5C |
/ |
/ |
5000 cycles |
/ |
The Genezen LFP system is engineered for resilience and adaptability in demanding environments. Its automatic transfer capability ensures seamless off-grid operation the moment grid power is lost. Modular design allows straightforward expansion as energy needs grow, while built-in PACK and cabinet fire protection provide superior safety. A high-voltage inverter with integrated photovoltaic input supports direct solar connection, reducing complexity and installation costs. With long-cycle discharge performance and consistent output delivery, the system delivers reliable power day after day.
| Model | Genezen LFP CSS 25kW/39kWh-H-F |
|---|---|
|
System Parameter |
|
|
Size (H*W*D) |
1870*680*600mm |
|
Weight |
500kg |
|
Protection Level |
IP65 |
|
Rated Voltage (V) |
384V |
|
Battery Type |
LFP |
|
Thermal Management Method |
Air-cooled |
|
Application Environment |
-20°C ~ 45°C |
|
Maximum Modules |
10 |
|
Working Temperature |
Discharge: -20°C ~ 55°C / Charge 0°C ~ 55°C |
|
Cell Technical Parameters |
|
|
Battery Model |
Genezen LFP 102Ah |
|
Weight |
1980±100g |
|
Size (H*W*D) |
117.9*160.3*49.99mm |
|
Maximum Charge and Discharge Rate |
1C |
|
Battery Energy |
326.4Wh |
|
Rated Voltage |
3.2v |
|
Cycle Life |
5000 cycles (70% SOH, 25°C) |
|
Battery Pack Parameters |
|
|
Model |
Genezen 102P38-F |
|
Series-Parallel Connection |
1P24S |
|
Pack Quantity (Each) |
5 |
|
Pack energy |
7.8336kWh |
|
System Energy |
39.168kWh |
The Genezen LFP Power Storage System combines advanced performance with uncompromising safety. Triple-layer protection and liquid cooling technology safeguard the battery during demanding operation, while charging and discharging efficiency of up to 90% maximizes usable energy. Its modular architecture and flexible connection options make it simple to scale capacity or configure to site needs. Whether used for emergency backup or peak demand expansion, the system delivers dependable power when it matters most.
| Model | Genezen LFP PSS 125kW/261kWh-B-Y | Genezen LFP PSS 250kW/522kWh-B-Y |
|---|---|---|
|
System Parameter |
|
|
|
Size (H*W*D) |
1300*1315*1995mm |
2280*1560*2370mm |
|
Weight |
2.3T |
4.5T |
|
Protection Level |
IP54 |
IP54 |
|
Rated AC Power |
125KW |
250KW |
|
System Energy |
261kWh |
522kWh |
|
System Conversion Efficiency |
90% |
90% |
|
Thermal Management Method |
Liquid Cooling |
Liquid Cooling |
|
Application Environment |
Support Environment Below C5 Anti-Corrosion Electrical Below IV Pollution |
Support Environment Below C5 Anti-Corrosion Electrical Below IV Pollution |
|
Rated Voltage (V) |
832V |
832V |
|
Voltage Range (V) |
650-949V |
650-949V |
|
Rated Current (A) |
157 |
314 |
|
Battery Type |
LFP |
LFP |
|
Working Temperature |
-30°C ~ 50°C |
-30°C ~ 50°C |
|
Cell Technical Parameters |
|
|
|
Battery Model |
Genezen LFP 314Ah |
Genezen LFP 314Ah |
|
Weight |
5.4kg |
5.4kg |
|
Size (H*W*D) |
207.01*174.70*71.72 |
207.01*174.70*71.72 |
|
Maximum Charge and Discharge Rate |
1C |
1C |
|
Battery Energy |
1004.8Wh |
1004.8Wh |
|
Rated Voltage (V) |
3.2V |
3.2V |
|
Cycle Life |
8000 Cycles (70% SOH, 25°C) |
8000 Cycles (70% SOH, 25°C) |
|
Battery Pack Parameters |
|
|
|
Model |
Genezen 314P52-Y |
Genezen 314P52-Y/YDC-314P104-Y |
|
Series-Parallel Connection |
1P52S |
1P52S*2S+1P52S |
|
Energy |
52.24KWh |
261.25KWh |
|
Quantity |
5 |
2 |
|
System Energy |
261.2KWh |
522.5KWh |
The Genezen BESS containerized LFP solution is designed for utility-scale performance and safety. Each PACK and battery cluster is protected by a built-in three-layer fire safety system and supported by advanced liquid cooling for stable operation under heavy load. With charging and discharging efficiency reaching 94%, the system delivers maximum usable energy while reducing losses. Its 1,500V platform enables peak shaving and emergency backup across demanding applications, and the ship-ready container format ensures fast, scalable deployment anywhere it is needed.
| Model | Genezen LFP BESS 5MWh-A | Genezen LFP BESS 4.04MWh-A |
|---|---|---|
|
System Parameter |
|
|
|
Size (H*W*D) |
6058*2438*2896mm |
6800*2550*2896mm |
|
Weight |
45T |
40T |
|
Protection Level |
IP54 |
IP54 |
|
Rated AC Power |
2.5MW |
4.04MW |
|
System Energy |
5.015MWh |
4.04MWh |
|
Series-Parallel Connection |
12P*1P416S |
10P*1P416S |
|
Thermal Management Method |
Liquid Cooling |
Liquid Cooling |
|
Application Environment |
Support Environment Below C5 Anti-Corrosion Electrical Below IV Pollution |
Support Environment Below C5 Anti-Corrosion Electrical Below IV Pollution |
|
Rated Voltage (V) |
1331.2V |
1331.2V |
|
Voltage Range (V) |
1123.2~1497.6V |
1123.2~1497.6V |
|
Rated Current (A) |
157 |
304 |
|
Battery Type |
LFP |
LFP |
|
Working Temperature |
-30°C ~ 50°C |
-30°C ~ 50°C |
|
Cell Technical Parameters |
|
|
|
Battery Model |
Genezen LFP 314Ah |
Genezen LFP 304Ah |
|
Weight |
5.4kg |
5.4kg |
|
Size (H*W*D) |
207.01*174.70*71.72 |
207.01*174.70*71.72 |
|
Maximum Charge and Discharge Rate |
1C |
1C |
|
Battery Energy |
1004.8Wh |
1004.8Wh |
|
Rated Voltage (V) |
3.2V |
3.2V |
|
Cycle Life |
8000 Cycles (70% SOH, 25°C) |
8000 Cycles (70% SOH, 25°C) |
|
Battery Pack Parameters |
|
|
|
Model |
Genezen YDC-314P104-Y |
Genezen 304P51-Y-TR |
|
Series-Parallel Connection |
1P104S |
1P52S |
|
PACK Energy |
104.49KWh |
50.5856KWh |
|
Quantity |
4 |
8 |
|
System Energy |
417.99KWh |
404.6848KWh |
Already IEC-approved with UL certification pending in 2025, the system meets stringent international standards for safety and performance. It will be ready for projects worldwide that demand both maximum output and uncompromising safety.
Genezen’s LFP battery technology is supported and upheld through independent performance testing. These credentials confirm compliance with strict safety, reliability, and operational standards.
This technology represents a significant leap forward in energy storage and will join the Genezen portfolio as our most powerful energy solution yet.
